2018 Haas UMC-750- 12K RPM

X-Axis Travel: 30 in (762 mm)

Y-Axis Travel: 20 in (508 mm)

 Z-Axis Travel: 20 in (508 mm)

Trunnion / Table:

  Table / Trunnion Type: Integrated dual-axis trunnion table

  Platter Size: 500 mm (approx. 19.7 in)

  Table Size: 630 mm × 500 mm (approx. 24.8 in × 19.7 in)

  Table Load Capacity: 300 kg (approx. 660 lb)

Rotary / Tilt:

  B-Axis (tilt): +110° / –35°

  C-Axis (rotation): 360° continuous

Spindle / Drive:

  Spindle Taper: 40-taper inline direct-drive

  Spindle Motor: 30 hp vector drive

  Standard Spindle Speed: 8,100 rpm

  Optional Spindle Speed: 12,000 rpm

Feed / Rapid Rates:

  Rapid Traverse (linear axes): 1,200 ipm (approx. 30.5 m/min)

Tool Changer:

  Tool Capacity: 40 + 1 side-mount automatic tool changer (SMTC)

  Tool Taper: CT40

Equipped with:
12,000 RPM
WIPS
TSC 1000PSI
HSM
Belt Chip Conveyor
40+1 ATC
Programmable Coolant
